Infrastructures

  • ISTAR
    ISTAR
    ISTAR
    ISTAR
  • Laboratory for Practical & Project work & by Students

    >

    Lab Equipments & Apparatus

    >

    Transducer Trainers:


    >

    Thermocouple,  RTD,  Strain Gauge, Load Cell, LVDT

    >

    Instrumentation & Control:

    >

    On-Off Control, PID Control, DC motor speed, DC servomotor

    >

    DC Motor Speed Measurement with Magnetic & Photoelectric

    >

    AC servo motor,

    >

    Control Engineering Board with RC Network


    >

    AC position control, Programmable Logic Control trainer

    >

    Power electronics


    >

    Silicon Controlled Rectifier, TRIAC


    >

    Uni-junction Transistor, Switch Mode Power Supply

    >

    Biomedical instrumentation


    >

    Electrocardio Graph, Electro Encephelograph


    >

    Electro Myograph, Blood Pressure Monitoring


    >

    Ultrasonic Measurement, Pacemaker trainer



    Microprocessor / Microcontroller



    >

    8085 Microprocessor kits, 8051 Microcontroller kits


    >

    Interfacing cards:


    >

    8155 PPI with Timer, 8255 PPI, 8253 Programmable Timer


    >

    8257 DMA, 8251 USART, 8259 PIC


    >

    8212 Latch Memory Decoder, Liquid Crystal Display, 373 Latch


    >

    8279, 6264 RAM, Digital to Analog converter


    >

    8086 Microprocessor kit

    >

    Computers- Debugging and Programming, Networking

    >

    Electronics


    >

    CRO trainer, Instrumentation amplifier


    >

    Digital to Analog converter, Voltage to Frequency converter

    >

    Communication Techniques


    >

    Amplitude Modulation / Demodulation


    >

    Frequency Modulation / Demodulation


    >

    Shift Keying trainer, Pulse Code Mod- Demodulation,


    >

    Time Division Multiplexing / De-multiplexing




    Fiber Optics Kit



    >

    LASER Trainer

    >

    Programmable Logic Controller





    Flow Measurement and Control Rig






    Temperature Measurement and Control Rig





    Level Measurement and Control Rig





    Siemens S7-300 PLC along with HMI Programming facility

    >

    Distributed Control System

    >

    Digital Signal Processor



    Robotics





    Robotic Arm





    Advanced Programming Applications



    Fuzzy Logic Controller

    >

    Test & Measurements


    >

    Power Supply, Power Scopes , Variable Dual Power Supply


    >

    Function Generators, Cathode Ray Oscilloscopes,


    >

    Digital Storage Oscilloscope


    >

    Digital Multi meters Bench type / Hand held


    >

    IC tester Universal , Microcontroller Programmer

    >

    Tools


    >

    Pressure Gauges, Oil baths , Electric heaters


    >

    Drill machine etc..


    >

    Calibrator
